L3000

$0.00

Description

Designed for new construction applications. This 6’’ fixed reflector luminaire houses a specification grade modular LED down light in 26W and 35W configuration. Incorporating the latest LED technology, this luminaire produces the lumen equivalent of up to a 150W halogen bulb providing both energy savings and low maintenance costs. Gasketed trim for wet (IP65).

Features

Mechanical

  • Housing constructed of 0.20’’ satin coated steel for a robust long life luminaire
  • Butterfly style mounting brackets provide up to 5’’ vertical adjustment which can accommodate ½’’ EMT
  • The junction box allows through branch wiring with 3 ½’’ knockouts
  • UL certified for damp and wet locations with the appropriate trims. See ordering instructions for various options Electrical

Electrical

  • 2000 lumens (26W), 3000 lumens (35W)
  • CRI≥81.5
  • Modular LED array assembly with colour temperature options of 2700K, 3000K, 3500K and 4000K
  • 120-277 VAC high efficiency, high power factor driver ≥0.91
  • Dimmable driver using 0-10V protocol with a dimming range of 10-100% and triac

Optics

  • Optical primary reflector of aluminized polycarbonate with optional beam angles provides precise beam control with reduced glare
  • Secondary reflector of spun aluminum
  • Third stage exterior lens of high impact acrylic lens diffuses the light output for a halogen lamp like appearance

Trim

  • Standard trim is a die cast aluminum trim with a standard polyester matte white powder coat, salt spray tested for 1000 hours
  • Custom colours are available as options
  • A gasketed trim option is also available. See ordering instructions for various options

Photometrics

  • Photometrics tested to IESNA LM-79-80 standard by an accredited photometric laboratory

Thermal Management

  • Proprietary heat sink design provides superior thermal management ensuring a minimum of 50,000 hrs of operation while maintaining a minimum of 70% lumen output
